MULTIMETER AUTO RANGE TRUE RMS

INGCO DM7504 Auto-Ranging Digital Multimeter – True RMS 6000 Counts

The INGCO DM7504 is an auto-ranging digital multimeter designed for electrical testing, troubleshooting and general measurement work. Its 6000-count True RMS display provides accurate readings across a wide range of electrical measurements, while features such as non-contact voltage detection, data hold, diode testing and continuity testing make it suitable for both professional and DIY users. INGCO also includes a flashlight, input jack LED indication and high-voltage warning functions.

Product Features

• 6000-count True RMS digital multimeter
• Automatic range selection
• LCD with double-colour backlight
• Non-contact voltage detection
• Live line or neutral line identification
• Data hold function
• Maximum/minimum recording
• Diode test
• Continuity test
• Frequency measurement
• Capacitance measurement
• Duty cycle measurement
• Temperature measurement
• Built-in flashlight
• Low-battery indication
• Automatic power-off function
• Input jack LED indication
• High-voltage warning
• Includes 2 × LR6 AA batteries
• Packed in colour box packaging

Common Applications

Suitable for electricians, technicians, maintenance personnel, workshop users and DIY enthusiasts. Ideal for troubleshooting electrical systems, checking voltage and current, measuring resistance and continuity, and carrying out general electrical testing.

Specifications

Brand: INGCO
Model: DM7504
Product Type: Auto-Ranging Digital Multimeter
Display: 6000 Counts True RMS
DC Voltage: 600mV / 6V / 60V / 600V / 1000V
AC Voltage: 6V / 60V / 600V / 750V
DC Current: 60µA / 60mA / 600mA / 10A
AC Current: 60mA / 600mA / 10A
Resistance: 600Ω to 60MΩ
Capacitance: 10nF to 100mF
Frequency: 10Hz to 10MHz
Temperature: -20°C to 1000°C
Safety Rating: CAT III 1000V / CAT IV 600V
Batteries: 2 × LR6 AA Included
Packaging: Colour Box
Packaged Weight: 0.41 kg
